50W Constant Power Inventronics Dimmable LED Driver
Fetaures High Efficiency (Up to 94.0%)Full Power at Wide Output Current Range (Constant Power)Adjustable Output Current
Basic Info.
| Model NO. | EUM-050 |
| Modulation System | Isolated 1-5V / 1-10V / 10V PWM / 3-Timer-Modes |
| Power Supply Voltage | 90~305 VAC |
| Pack Sealing Size | SMD |
| Brand | Inventronics |
| IP Class | IP66 / IP67 and UL Dry / Damp / Wet Location |
| Input Surge Protection | Dm 6kv, Cm 10kv |
| Warranty | 5 Years |
| Product Name | Inventronics LED Driver |
| Specification | 112(95)* 64*36.5mm |
| Origin | Zhejiang, China |
| Production Capacity | 10000 Pieces/Year |
Product Description
| Output Power (W) | Model No. | Full-powerCurrentRange(mA) | OutputVoltage Range(Vdc) | Eff.@ 220Vac | Lifetime (hours) | Dimensions(L*W*H)(mm) |
| 30 | EUM-030S050Dx | 300 ~ 500 | 30 ~ 100 | 88.00% | 120,000 Tc= 70°C | 112(95) × 64 × 36.5 |
| EUM-030S105Dx | 550 ~ 1050 | 17 ~ 54 | 87.00% | |||
| 50 | EUM-050S053Dx | 300 ~ 530 | 47 ~ 167 | 89.00% | 103,000 Tc= 70°C | 112(95) × 64 × 36.5 |
| EUM-050S090Dx | 550 ~ 900 | 28 ~ 91 | 89.00% | |||
| EUM-050S150Dx | 920 ~ 1500 | 17 ~ 54 | 88.00% | |||
| 75 | EUM-075S053Dx | 300 ~ 530 | 70 ~ 250 | 92.00% | 100,000 Tc= 70°C | 142(125) × 60 × 36.5 |
| EUM-075S105Dx | 700 ~ 1050 | 36 ~ 107 | 90.50% | |||
| EUM-075S150Dx | 1050 ~ 1500 | 25 ~ 72 | 90.50% | |||
| EUM-075S210Dx | 1400 ~ 2100 | 18 ~ 54 | 89.50% | |||
| 100 | EUM-100S053Dx | 350 ~ 530 | 94 ~ 286 | 94.00% | 114,000 Tc= 70°C | 148(131) × 60 × 36.5 |
| EUM-100S105Dx | 700 ~ 1050 | 48 ~ 143 | 93.00% | |||
| EUM-100S150Dx | 1050 ~ 1500 | 34 ~ 95 | 93.00% | |||
| EUM-100S280Dx | 1750 ~ 2800 | 17 ~ 54 | 92.00% | |||
| 150 | EUM-150S070Dx | 530 ~ 700 | 107 ~ 284 | 93.50% | 106,000 Tc= 70°C | 178(161) × 60 × 36.5 |
| EUM-150S105Dx | 700 ~ 1050 | 72 ~ 214 | 93.00% | |||
| EUM-150S150Dx | 1050 ~ 1500 | 50 ~ 143 | 93.50% | |||
| EUM-150S210Dx | 1400 ~ 2100 | 36 ~ 107 | 92.00% | |||
| EUM-150S420Dx | 2800 ~ 4200 | 18 ~ 54 | 91.50% | |||
| 200 | EUM-200S070Dx | 530 ~ 700 | 142 ~ 378 | 94.00% | 100,000 Tc= 70°C | 218(201) × 60 × 38.5 |
| EUM-200S105Dx | 700 ~ 1050 | 95 ~ 286 | 93.50% | |||
| EUM-200S150Dx | 1050 ~ 1500 | 67 ~ 190 | 93.00% | |||
| EUM-200S280Dx | 1800 ~ 2800 | 36 ~ 111 | 92.50% | |||
| EUM-200S560Dx | 3500 ~ 5600 | 18 ~ 57 | 92.00% | |||
| 240 | EUM-240S070Dx | 530 ~ 700 | 171 ~ 453 | 94.00% | 100,000 Tc= 70°C | 188(171) × 60 × 36.5 |
| EUM-240S105Dx | 700 ~ 1050 | 115 ~ 343 | 94.00% | |||
| EUM-240S150Dx | 1050 ~ 1500 | 80 ~ 229 | 93.50% | |||
| EUM-240S350Dx | 2150 ~ 3500 | 35 ~ 111 | 93.00% | |||
| EUM-240S670Dx | 4200 ~ 6700 | 18 ~ 57 | 92.50% | |||
| 320 | EUM-320S105Dx | 700 ~ 1050 | 153 ~ 457 | 94.00% | 111,000 Tc= 70°C | 243(224) × 80 × 44.5 |
| EUM-320S150Dx | 1050 ~ 1500 | 107 ~ 305 | 94.00% | |||
| EUM-320S250Dx | 1750 ~ 2500 | 64 ~ 183 | 94.00% | |||
| EUM-320S500Dx | 2850 ~ 5000 | 32 ~ 112 | 93.00% | |||
| EUM-320S760Dx | 5350 ~ 7600 | 21 ~ 60 | 93.00% |
Fetaures
High Efficiency (Up to 94.0%)Full Power at Wide Output Current Range (Constant Power)Adjustable Output Current (AOC) with ProgramabilityInput Voltage Range: 90 ~ 305VacCompact Metal Case with Excellent Thermal PerformanceOutput Lumen CompensationInput Surge Protection Up to: DM 6kV, CM 10kVAll-Around Protection: OVP, SCP, OTPIP66 / IP67 and UL Dry / Damp / Wet LocationSELV Output Models AvailableTYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location5-Year Warranty
