West Tune Apw

Basic Info.

Model NO.	APW-100
Trademark	RUNMEI
Origin	China
Production Capacity	500 Pieces/Day

Product Description

West Tune APW-100-M Microplate Medical Elisa Plate Reader and WasherSpecifications:

Model	APW-100
Residual liquid	≤0.5μl
Washing heads	1×8 or 1×12 heads
Plate types	Flat, U, V, C bottom
Washing volume	50~2000μl, increase by 50μl
Washing method	Central two points multi points
Washing times	99 times
Washing channels	3
bottle	3 pcs 2.5L washing bottle, 1pcs 2.5L waste bottle
Dispense accuracy	CV≤2.0% at 300μl (CV≤1.5% for 96 wells)
Soaking and Shaking time	19'59"
Number of wash protocols	up to 100
Data connection	USB
Dimensions(W x D x H)	345 x 460 x 200 mm
Weight	11.5kg
Power supply	AC100/240V, 50/60Hz

Product Features:
1. Low residual liquid, each well ≤0.5μl 2. Compatible for microplates: flat, U, V, C bottom 3. 4.3 inch color LCD display, easy to operate 4. Washing head position can accurate to 0.1mm 5. Wash parameters can be set to make sure the best washing effect 6. Support external U-disk, for program exporting 7. 100 programs can be saved 8. Uniform volume mark make it easy to measure the liquid 9. Automatic alarm for full liquid 10. Strainer in the pipeline and automatic washing functions avoid the liquid blocking the pipeline
Advantages:
1. The APW-100 is equipped with liquid position sensor to avoid the washing liquid used up or waste liquid from overflow, minimize the risk and avoid the liquid being sucked into the pump to break the equipment. Besides it has shaking function which can improve the washing efficiency.
2. The APW-100 Microplate Washer has 4.3 inch LCD display with friendly interface, U-disk can be used to transfer the datas between the PC and the washer or between two washers, it can also be used to upgrade the software. The washing head can be replaced easily for different kinds of microplates.
Product Pictures:Company Profile:
Hunan Runmei Gene Technology Co., Ltd. is a high-tech enterprise dedicated to "gene test product development and construction of big health big data service platform" initiated by a team of doctors with backgrounds of studying and working at famous universities and research institutes at home and abroad. Our company existing fluorescence quantitative PCR detection product development technology platform, through which the establishment of pathogenic microorganism nucleic acid detection kit product line; through the application of immunological technology platform to establish ELISA, colloidal gold and other detection reagent product lines. We have a professional technical team, advanced management mode and perfect business operation mechanism. "Survival by quality, development by innovation; win the market by speed, establish brand by service" is our company's quality policy. With its integrity and pragmatic style, the spirit of reform and innovation, our company has built a well-known brand in the industry and become a world famous company!

Certifications:
